OMNITRONIC LMC-1422FX USB Mixing Console

Schrijf uw review over dit product

€ 276,50 € 228,51

SKU

st10040280

Details

Reviews

OMNITRONIC LMC-1422FX USB Mixing Console

Professional audio mixer with British-style EQ, compressor, effect unit and USB interface

4 mono-ingangskanalen met gain-regeling, 3-weg EQ, low-cut en panregeling
2 stereo-ingangskanalen met drieweg-equalizer, niveauselectie en balansregeling
State-of-the-art, geluidsarme microfoonvoorversterkers met een dynamisch bereik van 130 dB en een hoge hoofdruimte
Uitzonderlijke Britse EQ's voor warm en muzikaal geluid
Studio-achtige compressoren met eenvoudige eenknopsfunctionaliteit en controlelampje op elk monokanaal
24-bit DSP FX-eenheid met 16 bewerkbare presets, tik op functie en instelbare gebruikersparameterinstellingen
Ingebouwde USB-audio-interface voor het opnemen en afspelen van digitale audiobestanden met een computer (pc en Mac)
2 aux sends per kanaal: aux 1 pre / post-fader omschakelbaar voor monitoring / FX-applicaties, aux 3 post fader voor interne FX
ALT 3-4-stereobus met afzonderlijke faders en uitgangen voor extra routeringsflexibiliteit
2 stereo aux-returns met flexibele routing
Clip-LED's en routeschakelaars voor mute en solo / PFL op alle kanalen
Gebalanceerde Main Mix-uitgangen met vergulde XLR-connectoren
Regelkamer / telefoons uitgangen met matrix matrix met meerdere ingangen
CD / tape-ingang toewijsbaar aan hoofdmix- of controlekamer- / telefoonuitgangen, CD / tape-uitvoer
Nauwkeurige 8-cijferige niveaumeter
FX dempen met afstandsbediening via voetschakelaar
+48 V fantoomvoeding, kan centraal worden geschakeld
Incl. beugels voor rackinstallatie

Power supply:	100-240 V AC, 50/60 Hz
Power consumption:	50 W
Inputs:
Mic:	XLR balanced; 2.6 kohms
Line (mono):	6.3 mm jack balanced; 10 kohms,
Line (stereo):	6.3 mm jack L/R balanced; 20 kohms
2-Track:	RCA L/R; 10 kohms
Aux Return:	6.3 mm jack L/R balanced; 10 kohms
Outputs:
Master:	XLR L/R balanced; max. +28 dBu
ALT 3-4:	6.3 mm jack balanced; max. +22 dBu
Control Room:	6.3 mm jack L/R unbalanced; max. +22 dBu
Aux Send:	6.3 mm jack L/R unbalanced; max. +22 dBu
Tape Out:	RCA L/R; max. +22 dBu
Headphones output:	6.3 mm jack unbalanced; max. +19 dBu
Headphones impedance:	>8 ohms
USB interface:	type B, 16 bit/48 kHz
Frequency range:	20-20000 Hz
Distortion:	0.05 %
S/N ratio:	110 dB
Crosstalk:	89 dB
Low Cut:	75 Hz, 18 dB/octave
Phantom power:	+48 V
Tone control mono channels:
Treble:	±15 dB at 12 kHz
Middle:	±15 dB at 100-800 Hz
Bass:	±15 dB at 80 Hz
Tone control stereo channels:
Treble:	±15 dB at 12 kHz
Low middle:	±15 dB at 3 kHz
High middle:	±15 dB at 500 Hz
Bass:	±15 dB at 80 Hz
Dimensions (L x W x H):	400 x 480 x 127 mm (incl. rack brackets)
Weight:	4.5 kg
