JBL 2268HPL 351210-003X 18" Neo Woofer refurbished

JBL 2268HPL 351210-003X 18" Neo Woofer

The JBL 2268HPL Differential Drive 18" speaker is the driver of choice for premium, high quality professional subwoofer systems.

if you want to buy one of these we can ship true europe for company's vat free contact us by email for this ) we have 2 pcs in stock at the moment .

Key Features
Tour-class woofer with patented motor design
Better heat dissipation increases power handling, reduces power compression
Reduced inductance extends upper response
Lightweight, compact neodymium magnet system
Push-pull operation lowers distortion
Magnetically shielded for use anywhere

Product Details
Brand JBL Professional
Model 2268HPL
Part Number 294-454
UPC 844632090899
Unit of Measure Each
Weight 15
Product Specifications
Nominal Diameter 18"
Power Handling (RMS) 800 Watts
Power Handling (MAX) 1600 Watts
Impedance 8Ω
Frequency Response 33 to 1,000Hz
Sensitivity 96dB 2.83V/1m
Voice Coil Diameter 3"
Thiele-Small Parameters
Resonant Frequency (Fs) 33Hz
DC Resistance (Re) 5.3Ω
Voice Coil Inductance (Le) 1.85mH
Mechanical Q (Qms) 3.8
Electromagnetic Q (Qes) 0.39
Total Q (Qts) 0.36
Compliance Equivalent Volume (Vas) 11.58ft³
Maximum Linear Excursion (Xmax) 8mm
Materials of Construction
Cone Material Paper
Magnet Material Neodymium
Mounting Information
Overall Outside Diameter 18.125"
Baffle Cutout Diameter 16.625"
Depth 8.875"
# Mounting Holes 8
Optimum Cabinet Size (determined using BassBox 6 Pro High Fidelity suggestion)
Sealed Volume 2.67ft³
Sealed F3 75Hz
Vented Volume 6.08ft³
Vented F3 44Hz
