JB Systems USB3.1-RDS Multimedia speler - tuner

Schrijf uw review over dit product

€ 296,10 € 244,71

SKU

B00364

JB Systems USB3.1-RDS

Details

Reviews

JB Systems USB3.1-RDS

Beschrijving

    De USB3.1-RDS combineert verschillende geluidsbronnen in een kleine 19"/1U-behuizing, die perfect is voor allerlei vaste installaties, zoals cafés, winkels, hotels, restaurants, winkelgalerijen, …:
        AM/FM-radio: met RDS en 18 voorkeuzestations
        CD-speler met sleuf: die zowel audio-CD's als MP3/WMA-bestanden afspeelt (ondersteunt CD-R en CD-RW discs)
        USB/SD-kaart mediaspeler: ondersteunt USB-sticks en SD/SDHC-kaarten tot maximaal 64GB
    Ondersteuning voor WMA- en MP3-bestanden tot maximaal 48kHz/320kbps
    Het LCD-scherm toont de namen van RDS FM-stations en ID3-tags (titel, artiest, ...) van MP3- en WMA-bestanden.
    Verschillende weergavemodi: normaal, willekeurig, herhaal een/map/alles.
    2 vaste en 1 gecombineerde tulpuitgangen:
        Perfect voor gebruik in een installatie met meerdere zones: De FM-radio en de media-/CD-speler kunnen gelijktijdig werken en verschillende muziek naar de aparte uitgangen sturen!
        Voor eenvoudige installatie is een gecombineerde uitgang voor “tuner en media-/CD-speler" met volumeregeling beschikbaar.
    De RS-232 ingang maakt afstandsbediening met bijvoorbeeld “automatiseringssystemen voor thuis" mogelijk.
    Noodstroomvoorziening 24 V gelijkspanning op EuroBlock-connector.

Technische Informatie

    Power Supply:   AC 110-240V 50/60Hz or DC+24V
    Fuse: T500mAL/250V
    Power Consumption: 10W
    Fixed Output level (@ 1kHz,0dB): CD/USB: 1.22 Vrms     RADIO: 1.22 Vrms
    Variable Output level (@ 1kHz,0dB): 0 ~ 1.22 Vrms
    RADIO FM
        Frequency range: 87.5 ~108.0 MHz
        Channel Step: 50kHz
        Intermediate freq. : 10,7 MHz
        Sensitivity: 2uV @ 30dB S/N
        Signal / noise ratio: >60dB
    RADIO AM
        Frequency range: 522 ~1620 kHz
        Channel Step: 9kHz
        Intermediate freq. : 455 kHz
        Sensitivity: 30dB
        Signal / noise ratio: >50dB
    AUDIO PLAYER:
        Signal / noise ratio:   >80dB
    FORMATS: WMA + MP3 formats
    MP3 FORMAT:
        Possible file extensions: .mp3 ~ .MP3 ~ .mP3 ~ .Mp3
        ISO9660:   max. 63 character style
        Joliet: max. 63 character style
        CD-ROM sector format: mode-1 only
        USB file system: FAT 32
        Max. capacity USB-memory: 64GB
    MP3 FORMATS PLAYBACK:
        MPEG1 Layer3 (ISO/IEC11172-3):   mono / stereo sampled at: 32 - 44,1 - 48kHz
            Bitrates: 32 – 320 Kbps
            Bitrate modes: CBR (Constant Bitrate), VBR (Variable Bitrate) or Xing
        MPEG2 Layer3 (ISO/IEC13818-3):               mono / stereo sampled at: 16 – 22,05 - 24kHz
            Bitrates: 32 – 160 Kbps
            Bitrate modes: CBR (Constant Bitrate), VBR (Variable Bitrate) or Xing
        MPEG2,5 Layer3: mono / stereo sampled at: 8 – 11,025 - 12kHz
            Bitrates: 32 – 160 Kbps
            Bitrate modes: CBR (Constant Bitrate), VBR (Variable Bitrate) or Xing
    Dimensions: 482(W) x 44(H) x 330 (D) mm
    Weight: 3.82kg
