EUROLITE DMX Split/Boost 8 PRO 3-pin 2 in/8 out DMX splitter with RDM

EUROLITE DMX Split/Boost 8 PRO 3-pin 2 in/8 out DMX splitter with RDM

Name: EUROLITE DMX Split/Boost 8 PRO 3-pin 2 in/8 out DMX splitter with RDM
SKU: st70064834
Price: 352.775501 EUR
Availability: InStock

Schrijf uw review over dit product

€ 352,78 € 291,55

SKU

st70064834

EUROLITE DMX Split/Boost 8 PRO 3-pin 2 in/8 out DMX splitter with RDM support and real-time DMX monitoring

Details

Reviews

EUROLITE DMX Split/Boost 8 PRO 3-pin 2 in/8 out DMX splitter with RDM support and real-time DMX monitoring

Features

2 in/8 out DMX splitter with RDM support and real-time DMX monitoring

DMX modes: LTP, HTP, merge or backup
Each DMX output with independent driver and status indicator
Control via RDM
Multicolor OLED display
Mains input and output for power linking up to 8 units
Built with SEETRONIC connector
(19") 48.3 cm rack installation 1 U
For application areas such as: Installation; Stage; theater; Rental
Silent operation
Application possibility: Standing

Package contents

1 x device, 1 x power cord, 1 x user manual

Technical specifications

Power supply:	100-240 V AC, 50/60 Hz
Power consumption:	5 W
IP classification:	IP20
Protection class:	Protection class I
Power connection:	Mains input via P-Con (blue), mounting version power supply cord with safety plug
Cable construction:	3 x 1,0 mm² H05VV-F
Cable length:	1,45 m
Power output:	P-Con (gray), mounting version
Fuse:	5 x 20 mm, T 1 A fuse replaceable
DMX input:	2 x 3-pin XLR (M) mounting version
DMX output:	8 x 3-pin XLR (F) mounting version Separate (galvanic) with independent driver and status indicator
Control:	RDM
Housing color:	Black
Attachment system:	M10 thread
Display type:	Multicolor OLED display
Use of brands:	Built with SEETRONIC connector
Material:	Metal
Housing design:	(19") 48.3 cm rack installation 1 U
Mounting depth:	23 cm
Dimensions:	Width: 48,3 cm Depth: 16 cm Height: 4,4 cm
Weight:	2,23 kg
Noise classification:	Class 0 (no noise at all)
