Eminence Kilomax Pro 18 A
€ 466,00
?
SKU
EMN-KILOMAXPRO-18A
Eminence Kilomax Pro 18 A
Eminence Kilomax Pro 18 A
18" Speaker 1250 W 8 Ohm - die-cast Basket
Type
Subwoofer
Nominal Diameter
18 "
Nominal Diameter
457.2 mm
Voice Coil
4 "
Voice Coil
101.6 mm
Overall diameter
457.2 mm
Pitch Circle Diameter
438.2 mm
Section Diameter
420.6 mm
Diameter of fixing holes
7 mm
Depth
207 mm
Nominal Impedance
8 Ohm(s)
Nominal Load Capacity
1250 W
maximum rated load
2500 W
Sensitivity (1 W / 1 m)
95.8 dB
Frequency response
33 - 300 Hz
Voice Coil Material
copper
Magnet
Ferrite
Depth of the magnetic gap
9.53 mm
Thiele & Small Parameter
Fs (Resonance Frequency)
32 Hz
Re (DC resistance)
5.07 Ohm(s)
Qms (mechanical quality)
10.15
Le (inductance of the voice coil)
1.59 mH
Qes (electrical quality)
0.49
Qts (overall quality)
0.47
Vas (equivalent volume)
331.5
Mms (moving mass)
143.17 g
BL (power factor)
17.2 T/m
Xmax (maximum displacement)
10 mm
Cms (elasticity of the suspension)
0.18 mm/N
Sd (membrane area)
1159 cm²
Weight
14,02 kg
