DAP CA-4500 DSP 4-kanaals DSP-aangedreven versterker

DAP CA-4500 DSP 4-kanaals DSP-aangedreven versterker

Name: DAP CA-4500 DSP 4-kanaals DSP-aangedreven versterker
SKU: D4515
Price: 788.799001 EUR
Availability: InStock

Schrijf uw review over dit product

€ 788,80 € 651,90

SKU

D4515

DAP CA-4500 DSP 4-kanaals DSP-aangedreven versterker

Details

Reviews

DAP CA-4500 DSP 4-kanaals DSP-aangedreven versterker\

De DAP CA-4500 DSP-versterker is een 4 x-kanaals digitale versterker met een vermogen van 500 W per kanaal in 4Ω. In brugmodus wordt het een stereoversterker met een vermogen van 1000 W per kanaal. De CA-4500 bevat een krachtige DSP waar alle parameters kunnen worden bewerkt via een ingebouwd OLED scherm met een encoder of via een PC met behulp van de software editor. DSP-functies omvatten 8-bands EQ, noise gate, compressor en delay met temperatuurinstelling. Werkmodi en kanaalroutering zijn ook beschikbaar en kunnen eenvoudig worden bewerkt zoals andere DSP-parameters. De CA-4500 is zeer compact (1U rack) en licht (8kg), dus het is een perfecte versterker voor hoog vermogen vaste of mobiele toepassingen.

Uitgangsvermogen
4ch 2Ohm	Niet toegestaan
4ch 4Ohm	4x 500 Watt RMS 4x 500 Watt RMS
4ch 8Ohm	4x 250 Watt RMS 4x 250 Watt
Brug 2Ohm	Niet toegestaan
Brug 4Ohm	Niet toegestaan
Brug 8Ohm	2x 1000 Watt RMS: 2x 1000 Watt.
Frequentiebereik	20Hz - 20KHz, +0/-1dB, +0/-1dB
THD	<0.15%
S/N tarief	>96 dB A-gewogen
Overspraak	>60dB
Dempingsfactor	>180
Aanwinst	34db
Inputgevoeligheid	0,9-1,1V (+/-1dBv)
Ingangsimpedantie	20kOhm gebalanceerd, 10kOhm uit balans, 10kOhm ongebalanceerd.
Uitgangsmodus	4-kanaals / Stereo / Overbrugd
Amp Technologie	Klasse D
Stroomvoorziening	SMPS
Bescherming	Clipbegrenzer
	Kortsluiting
	Oververhitting
	Overbelasting
	Ultrasoon
	Gelijkspanning
	Zachte start
Koeling	Gedwongen lucht door axiale ventilator
Luchtstroom	Van voor naar achter
Ingangsaansluitingen	3-pins XLR 3-pins
Uitgangsaansluitingen	Spreken
Stroomaansluiting	IEC
Ingangsspanning	210~240VAC.... 50/60Hz... 50/60Hz
Stroomverbruik	1100W
Afmetingen	483x285x44,5mm (BxDxH)
Inbouwdiepte	285mm (excl. conn.)
Gewicht	5,9kg
